Hose Reel Drum

Hose Reel Drum
Hose Reel Drum
Product Code : HRD-1
Brand Name : SUPEREX
Product Description

In order to meet the diversified requirement of the customers, our organization is affianced in manufacturing and supplying of a precision engineered Hose Reel Drum. Our offered reeling drums are used in fire fighting operations for controlling the flow and direction of water. Further, in order to maintain the quality and avoid any kind of flaw, the entire range of Hose Reel Drum is checked by our experienced quality controllers on various parameters.

Features



  • Available with 1 year warranty
  • Trouble free performance
  • Maximum mechanical strength



First Aid Hose Reel (Swinging Type) / Hose Reel Drum

(A) General Specifications

Type -A

Swinging (180deg wall mounting)

Nozzle

IS : 8090 - 1976

Hose Reel tubing

Hydraulic Rubber Hose IS : 444-1980, Thermo-Plastics Hose IS:12585

Manufactured

IS:884 / 85

(B) Dimensions

Side disc dia.

500 mm.

Hub width

230 mm.

Wall bracket base to swing center

325 mm.

Mounting hole pitch in wall bracket

140 mm. 180 mm +- 10

Sheet thickness of Hub

1.2 mm.

Thickness of drum

1.5 mm.

Thickness of wall bracket

2.8 mm.

(C) Material Used

Hub

M.S. Sheet (IS : 513 - 1973)

Sides

Mild Steel Sheet (1S : 513 - 1973)

Wall Bracket

Mild Steel Sheet (IS : 513 - 1973)

Swivel Joint

Leaded Tin Bronze (Grade LTB 2 of IS: 318 - 81)

Stop Valve

IS : 778-1979

Pipe with fitting

Steel as per IS : 1239 (Part - 1)

(D) Performance Test

Water Flow Rate

24 LPM (Litre Per Minute)

Test Pressure

7 Kgf/cm2 for Type-I , 10.2 Kgf/cm2 for Type-II

(E) Specification- IS: 884

(F) Warranty- 1 year.
